- Features
- Torque: 1–20 ft-lb
- Torque Accuracy: +/- 2% CW and +/- 3% CCW, 20–100% of full scale; +/- 4% CW and +/- 6% CCW, 10–19% of full scale; +/- 4% CW and +/- 6% CCW, 10–19% of full scale
- Manual preset and automatic track and peak hold modes
- Torque units conversion: N• m, ft-lb, in-lb
- Audible (tone) and tactile (vibrating handle) preset alerts
- Display resolution: 0.1 ft-lb, 0.1 N•m, 1 in-lb
- Each button has only one function (power on, preset increase, preset decrease, unit of measure select)
- Comfortable, non-slip grip
- Stand on handle bottom keeps tool from rolling off flat surface
- Sealed flex-head ratchets move ±15°
- Low battery indicator and auto shut off (after two minutes idle)
- Uses (3) AA lithium batteries (included)
- Includes storage case
- Specifications
-
| Range, ft-lb |
2–20 |
| Operating Temperature |
40–110 °F (5–42 °C) |
| Housing Color |
Red |
| Range, in-lb |
24–240 |
| Gear Action |
5° |
| Country Of Origin |
USA |
| Storage Temperature |
0–122 °F (-20–50 °C) |
| Storage Case |
PBTECH2 |
| Gear Teeth |
72 |
| Battery, Type (qty) |
AA Alkaline (3) |
| Length, inches |
15-1/4 |
| Head Width, inches |
7/8 |
| Range |
2.71–27.12 N•m |
| Ratchet Service Kit |
RKRT72A |
| Head Type |
Sealed Fixed Ratchet |
| Square Drive, inches |
1/4 |
| Head Depth, inches |
7/16 |
| Humidity |
Up to 90% Non-Condensing |
