| Internal Batteries, Type (qty) |
AA (6) |
| Cable Length, feet (m) |
10 (3) |
| Clamps |
Large |
| CCA Input |
Yes |
| System Voltage |
12 or 24 |
| Heavy Duty Battery Pack |
Yes, Series/Parallel (1–6) |
| Ideal Operating Temperature |
5–104 °F (-15–40 °C) |
| USB Drive |
Future update or data download |
| Displays Battery Voltage (SOC) |
Yes |
| Clock Battery |
BR1225 Lithium |
| Overal Width x Height x Depth, inches (cm) |
10-1/2 x 6-1/2 x 3 (25.67 x 16.51 x 7.62) |
| Volts |
6/8-12/24 (24 V Truck Packs of 12 V only, no 24 V Aviation Batteries) |
| Battery Type |
Flooded, AGM, Gel, ISS EFB |
| Weight |
3 lb 14 oz |
| Country Of Origin |
USA |
| V DC Range |
1–35 |
| Voice Prompts |
— |
| Wireless Controller |
No |
| Languages – Print and Screen |
English, Espanol, French, German, Italian, Dutch, Japanese, Portuguese |
| Integrated Printer |
Yes |
| Discharged Battery Test |
Down to 1 V |
| Printer Capable |
Integrated |
| Displays % of CCA |
Yes |
| Model |
Advanced |
| Reverse Polarity |
Yes – Protection and Detection |
| Bad Cell Detection |
Yes |
| Post/Stud Adaptors |
Yes |
| System Test |
Yes – Menu-Driven Routine with Ripple Detection and Graph |
| Battery Voltage |
6/8/12/24 (24 V Truck Packs of 12 V only, no 24 V Aviation batteries) |
| Surface Charge Warning |
Yes |
| Heavy Duty Battery Type |
Group 31, 4D, 8D |
| CCA Range |
100–2,000 |
| Test Results Stored |
Last 10 tests |
| Communication |
IR to PC, USB |
| Retention |
Hanger |
| Displays Battery Condition |
Yes |
| Custom Header with Date and Time |
Yes |
| Temperature Compensation |
4 Ranges |
| Repair |
Snap-on® Service Center |
| Poor Connection Detection |
Yes |
| Displays Battery State of Charge |
Yes |
| Warranty, Years |
2 |
| Rating Systems |
CCA, SAE, EN, IEC, DIN, JIS, MCA |
| Cable Integrity Technology |
Yes |
| Display |
Color 3-1/2" (1/4 VGA) |
