| Vehicle Database Testing |
Through VIN scan or Year/Make/Model Scrollable Selection |
| Clamps |
Large |
| CCA Input |
Yes, VIN Scan and Manual |
| System Voltage |
12 or 24 |
| Heavy Duty Battery Pack |
Yes, Series/Parallel (1–6) |
| USB-C Port |
Future Updates, Data Download, Charging |
| Displays Battery Voltage (SOC) |
Yes |
| Volts |
6/8-12/24 (24 V Truck Packs of 12 V only, no 24 V Aviation Batteries) |
| Battery Type |
Flooded, AGM, Gel, EFB and Pure Lead (Formerly Northstar) |
| Battery Tests |
Overall Result, State of Health Graph, Voltage, Measured CCA, Measured Resistance, Temperature, Battery Chemistry |
| Ideal Operating Temperature, °F (°C) |
5–104 (-15–40) |
| Country of Origin |
USA |
| V DC Range |
1–40 |
| Languages – Print and Screen |
English, Espanol, French, German, Italian, Dutch, Japanese, Portuguese |
| Battery Pack |
Yes, Series/Parallel |
| Integrated Printer |
Yes |
| Printer Capable |
Integrated |
| Displays % of CCA |
Yes |
| Model |
Advanced |
| Reverse Polarity |
Yes, Protection and Detection |
| Post Location |
Top, Side, Remote |
| Weight, lb |
2 |
| Bad Cell Detection |
Yes |
| Post/Stud Adaptors |
Yes |
| System Test |
Yes, Starter, Cranking, Cranking V, Ripple Curve, Ripple V, Charger Result |
| Battery Voltage |
6/8/12/24 (24 V Truck Packs of 12 V only, no 24 V Aviation batteries) |
| Battery Testing Technology |
Conductance |
| Surface Charge Warning |
Yes |
| Cable Length, inches (cm) |
30 (76.2) |
| Heavy Duty Battery Type |
Up to 6 Batteries in Series or Parallel (Group 31 / Comm 4D-8D / Pure Lead) |
| CCA Range |
100–3,000 |
| Application |
Automotive /Motorcycle /Marine / Lawn & Garden /Group 31 / Commercial 4D-8D /AG and Tractor |
| Test Results Stored |
Rolling 1,000 |
| Internal Battery Type |
Rechargeable Li-Ion Batteries |
| Communication |
Wi-Fi® and USB-C |
| Overal Dimensions, inches (cm) |
10.5 x 4.8 x 2.3 (26.7 x 12.2 x 5.8) |
| Retention |
Kickstand |
| Displays Battery Condition |
Yes |
| Custom Header with Date and Time |
Yes, User Programmable 5 Fields |
| Repair |
Snap-on® Service Center |
| Poor Connection Detection |
Yes |
| Full Color Display, inches |
4.3 |
| Warranty, Years |
2 |
| Rating Systems |
CCA (100–3,000) / CA (100–3,000) / JIS (part numbers) / DIN (100–1,000) /SAE (100–3,000) / IEC (100–1,000) /EN (100–1,700) / EN2 (100–1,700) /MCA (100–3,000) |
