| Carbon Monoxide |
0–5% (Accuracy ±10%) Res 0.01% |
| Handset Dimensions |
7.9 x 1.8 x 3.5" (200 x 45 x 90 mm) |
| Lamda/AFR (Air Fuel Ratio) |
0.6–1.4 / 8.82:1–20.58:1 (Gasoline) |
| Replacement Probe Spigot |
HHGA-14 |
| Pre Programmed Fuels |
Gasoline/LPG/CNG |
| AC Adaptor, Input |
100–240~ /50–60 Hz/300 Ma |
| EN 61000-6-3 |
Compliant |
| Screen |
Six Line Backlit LCD w/ Screen Protection |
| Replacement Probe |
HHGA-9 |
| Bluetooth |
Yes – Class 1 |
| Auto Re-Zero |
Yes (every 30 minutes) |
| Country Of Origin |
GBR |
| CE Approved |
Yes |
| Oxygen |
0–21% (Accuracy ±5%) Res 0.02% |
| Warranty |
1 Year |
| Corrected CO |
0–5% Calculation |
| Sensor replacement |
Service Center Only – Crystal Lake |
| Electrochemical Sensors |
Measure O2 and NO |
| AC Adaptor, Output |
9 VDC/1 A |
| EN 61000-6-1 |
Compliant |
| Print Function |
IR emitter to HHGA-PRINTER (Optional on HHGA5C) |
| Battery Life |
120 Minutes (on standby) From Full Charge |
| 12 V Car Charger included |
Yes |
| Hydrocarbons |
0–2,000 PPM (Accuracy ±10%) Res 1 PPM |
| Oxides of Nitrogen |
0–1,500 PPM (Accuracy ±10%) Res 1 PPM |
| Handset Weight, lb (kg) |
2.2 (1) |
| Service and Calibration |
As required – Recommend Annually |
| Replacement Filters |
HHGA-11 |
| Internal Memory |
Yes – Stores 100 tests (manual or automatic) |
| Infra-red Sensors |
Measure CO, CO2 and HC |
| Carbon Dioxide |
0–15% (Accuracy ±10%) Res 0.1% |
