Use in the following six quick steps: get the app, select unit of measure, connect leads to circuit, sync to remote device, take readings then diagnose, store and share results (mobile device sold separately)
-
Horizontal orientation is comfortable for button and dial operation
-
Large color display for excellent viewing
-
Bluetooth® remote display allows for one-tech testing, such as brake lights (mobile device sold separately)
-
Stores customer information and test results, with the ability to share via email, text or social media (mobile device sold separately)
-
CAT-III 1,000 V / CAT-IV 600 V hybrid safety rated
-
Convenient test lead storage wrap with retention strap
-
Built-in tilt stand and optional strap hanger (EEDMMAGSTRAP) for easy viewing
-
LCD Display: 40,000 count with 42-segment bar graph
-
REC: Record mode stores minimum, maximum and average readings over a measurement period
-
RANGE: Manually select range or allow auto-ranging
-
FUNCTION: Toggle between functions on Ohm, TEMP and IG modes
-
REL (Relative Mode): Factor out lead resistance for improved low ohm measurements or compare readings to a known standard—can also be used for differential measurements
-
CYL (Cylinder): Selects the number of cylinders in IG mode
-
HOLD: lock the reading on the display for hard to read locations or future reference
-
PEAK-H (Peak Hold): Capture signals spikes as fast as one millisecond to diagnose intermittent events
-
Hz (Frequency): Measure the frequency of sensors and signals
-
AC mV and DC mV Ranges: Additional 40 mV DC range with 0.01 mV resolution for improved accuracy when performing low voltage measurements
-
DC V, AC V (DC Volts, AC Volts): Measure the voltage of circuits, sensors and ABS wheel sensors
-
TEMP (Temperature): Measure temperature with included temperature probe
-
AC/DC Current Functions: Measure the parasitic draw from the battery
-
IP, IG (Automotive Functions): Measure RPM, Duty, Dwell, mS pulse width, Frequency
-
AC/DC: Manually select AC or DC measurement function
-
Quickly Test Condition of Internal Fuses: Determine the status of the internal fuses before you open the battery/fuse compartment
-
Built-in Tilt Stand: Tilt stand is built into the instrument housing, adding strength and integrity to the design
-
Capacitance: Measure the capacitance of condensers or capacitors found in today’s hybrid automobiles
